· 产品简要说明：
· Feature
1.采用触摸式可编程微电脑控制，屏幕点阵液晶显示，中文人机对话界面，可实现初洗、洗涤、消毒、过清、漂白、脱水等。
PLC touch panel with LCD display, pre set process of laundry, degassing,rinsing and extracting.
2.洗衣缸采用统胆式，无隔仓，装料方便。自动开门、关门、出料自动倾斜。
Straight tube type washing cylinders, easy loading; Automatic open&close door, automatic tilting when unloading clothes;
3.本机各控制阀采用气动控制，动作可靠，并采用双管后排水结构，排水，无污染。
Pneumatic control valve, fast and reliable; Dual drain pipe, fast and Eco-friend;
4.采用质不锈钢制作，抗腐蚀性强，经久耐用。
Stainless structure, strong corrosion resistance and durable;
5.采用变频速度、耗能、电机启动运行平稳。速脱水设置为一至四个速度，可根据不同洗涤物选择不同的洗涤速度。悬浮结构避振，振动小，无需殊基础。
VFD drive, low energy consumption, motor start and running smoothly; Four optional speed, adjust speed according to different clothes; Fully suspended structure to avoid vibration, freestanding
· Feature
1.采用触摸式可编程微电脑控制，屏幕点阵液晶显示，中文人机对话界面，可实现初洗、洗涤、消毒、过清、漂白、脱水等。
PLC touch panel with LCD display, pre set process of laundry, degassing,rinsing and extracting.
2.洗衣缸采用统胆式，无隔仓，装料方便。自动开门、关门、出料自动倾斜。
Straight tube type washing cylinders, easy loading; Automatic open&close door, automatic tilting when unloading clothes;
3.本机各控制阀采用气动控制，动作可靠，并采用双管后排水结构，排水，无污染。
Pneumatic control valve, fast and reliable; Dual drain pipe, fast and Eco-friend;
4.采用质不锈钢制作，抗腐蚀性强，经久耐用。
Stainless structure, strong corrosion resistance and durable;
5.采用变频速度、耗能、电机启动运行平稳。速脱水设置为一至四个速度，可根据不同洗涤物选择不同的洗涤速度。悬浮结构避振，振动小，无需殊基础。
VFD drive, low energy consumption, motor start and running smoothly; Four optional speed, adjust speed according to different clothes; Fully suspended structure to avoid vibration, freestanding
| 型号Model | XFQ-200 |
| 内胆容量（干物）kg Rated capacity (dry loading) | 200 |
| 内胆直径×长度mm Inner drum (D×L) | ∮1600×1100 |
| 洗衣缸直径×长度mm Outer drum (D×L) | ∮1720×1230 |
| 洗衣/均布转速rpm Washing/distributing speed | 25/52 |
| 中速脱水转速rpm Middle extracting speed | 290 |
| 速1-4脱水转速 High (1-4) extracting speed | 360/470/580/650 |
| 电机功率 kw Motor Power | 30 |
| 取衣倾斜角度a Tilting angle of unloading | 15° |
| 蒸汽管通径DN Steam pipe | 40 |
| 冷/热水管通径DN Cool/hot water pipe | 50 |
| 排水管外径mm Water drain pipe | ∮114(2 pcs) （2pinpes） |
| 压缩客气接管通径mm Connecting pipe of compressed air | ∮10 |
| 蒸汽压力MPa Steam pressure | 0.4-0.6 |
| 自来水压力MPa Tap water pressure MPa | 0.2-0.4 |
| 压缩空气工作压力MPa Compressed air pressure | 0.4-0.6 |
| 每车耗水量kg Water consumption per cycle | 2.4 |
| 每车耗电量kw.h Power consumption per cycle | 2.6 |
| 每车耗蒸汽量kg Steam consumption per cycle | 85 |
| 配备空气压缩机流量m³/min Flow of air compressor | 0.13 |
| 电源V/P/Hz Power supply | 380/3/50 |
| 外形尺寸（长×宽×）mm Dimension (L ×W×H) | 2550×2250×2240 |
| 整机重量约kg Weight | 6500 |
